A Trust Layer for x402

The design is live

In the whitepaper announcement we previewed an ADVANCED scenario: agents that carry proofs and settle payments in a single flow. Today that scenario ships as a working reference implementation.

Repository: github.com/lemmaoracle/example-x402
Service: Trust402 — ZK-Verified Agent Payments

Live on Base Sepolia. We offer this trust layer as a service under the name Trust402.

The gap x402 leaves

x402 reactivated 402 Payment Required and turned HTTP into a payment rail an autonomous agent can speak natively. No account, no API key, no invoice form — a wallet and an HTTP request are enough. Coinbase, Cloudflare, Google Cloud, AWS, Visa, and Mastercard have aligned around it as founding members of the x402 Foundation. The infrastructure for agents-as-economic-actors is being put in place.

But x402 alone settles the payment. It does not tell the receiving server:

• Who authorized the payment. The payer is a wallet address. A wallet address is an anonymous primitive, not a principal.
• Under what policy. Role, scope, spend limit — none of these are visible to the resource.
• Whether the data returned will arrive intact. Once the bytes leave the server, the receiving agent has no cryptographic way to confirm that what it parses is what was settled for.

For agents-paying-agents to become an economy rather than a curiosity, those three questions must be answerable in the same HTTP round trip as the payment itself.

What this adds

Every x402 settlement in this implementation now carries a ZK proof bundle inside PAYMENT-RESPONSE. The bundle is independently verifiable by downstream consumers — a second-leg agent, a smart contract, an auditor — without re-running the round trip.

The bundle covers three claims, with selective disclosure as a fourth available on demand.

Issuer identity

The party that issued the verified data (the issuer) and the document subject are recorded on chain as a Poseidon Merkle commitment. A verifier can match the issuerId / subjectId returned in the response against the on-chain commitment to confirm cryptographically that the data was issued by exactly that party. Substituting the issuer after the fact, or fabricating a past issuance, is not structurally possible.

Settlement

In the standard x402 flow, the evidence of payment is essentially the transaction field carrying a tx hash. Lemma's extension delivers the full settlement proof bundle in addition to the tx hash, packaged inside the extensions.lemma block of PAYMENT-RESPONSE. A downstream verifier — a second-leg agent, or a smart contract that needs to confirm receipt — can validate the payment simply by holding the response, without running the x402 round trip again.

Data integrity

The SHA-256 of the response body is bound at issuance to the on-chain commitment (docHash). The receiving agent computes SHA-256 over the bytes it actually received and compares it to attributes.integrity returned in the response. A match means the bytes are identical to those committed at issuance. No round trip back to Lemma is required.

Selective disclosure

As a fourth claim, POST /query provides selective disclosure — the ability to reveal only a chosen subset of attributes from a larger signed set, while keeping the rest cryptographically attested but invisible. We implement this with the BBS+ signature scheme.

For example, suppose a research dataset is signed with attributes like author, institution, published, funding-source, coauthors, and salary. A verifier can request disclosure of just author and published. The remaining attributes stay sealed but provably part of the original signed set. Privacy and verifiability are satisfied at the same time, instead of trading one off against the other.

Lemma further binds this disclosure to the x402 settlement via the condition condition.circuitId = "x402-payment-v1". Only the party that actually executed the corresponding x402 payment can re-derive the disclosure; copying or replaying it without making the payment is structurally impossible. Payment and disclosure become two faces of the same cryptographic fact.

Four phases per request

The packages/agent/src/index.ts reference agent walks through four phases:

1. Free fetch
   • GET /resource returns the data and an X-Lemma-Attestation header (or a <link rel="lemma-attestation"> in HTML) pointing at the verification endpoint.
   • Distribution is cheap; the proof is what costs $0.001.
2. Hold as UNVERIFIED
   • The agent's reasoning loop receives the bytes labeled untrusted.
   • It does not yet act on them.
3. Pay-and-verify in one round trip
   • GET /verify/:hash via @x402/fetch returns 402 Payment Required.
   • The agent auto-pays 0.001 USDC on Base Sepolia.
   • The 200 response carries the verified attributes in the body and the ZK settlement proof in the PAYMENT-RESPONSE header.
4. Integrity check
   • The agent computes SHA-256(body) and compares it to attributes.integrity.
   • Only on match does it transition internal state to VERIFIED.

Phase 3 is the moment payment and proof become a single artifact. The PAYMENT-RESPONSE extension produced by @lemmaoracle/x402 is:

type PaymentResponseExtension = {
  transaction: string;
  network: string;
  payer?: string;
  extensions?: {
    lemma?: {
      proof: string;
      inputs: string[];
      circuitId: string;
      generatedAt: number;
    };
  };
};

Anyone holding the response can validate the proof against the on-chain commitment. The Lemma facilitator never needs to be consulted again.

How to integrate

The trust layer is added as a single middleware on the resource server.

The @lemmaoracle/x402 package shares the same API signature as Coinbase's @x402/* packages. In an existing x402 server, replacing imports from @x402/* with @lemmaoracle/x402 is enough to enable ZK proof emission automatically.

import {
  paymentMiddleware,
  x402ResourceServer,
  ExactEvmScheme,
  HTTPFacilitatorClient,
} from "@lemmaoracle/x402";
import { createFacilitatorConfig } from "@coinbase/x402";

const resourceServer = new x402ResourceServer(
  new HTTPFacilitatorClient(facilitatorConfig)
).register("eip155:84532", new ExactEvmScheme());

app.use("*", paymentMiddleware(routes, resourceServer));

Route handlers stay untouched. Business logic does not change. The x402ResourceServer constructor automatically registers a Lemma extension (keyed lemma) via enrichSettlementResponse. After settlement, the extension generates the ZK proof and writes it into the extensions.lemma block of PAYMENT-RESPONSE before the response headers are sent.

The agent side requires no changes either. Stock @x402/fetch from Coinbase is enough — read extensions.lemma from the PAYMENT-RESPONSE header and verify. No Lemma-specific client SDK is needed.

The full integration cost of the trust layer is a single import line on the server. Teams already operating x402 can keep their business logic as-is and add the trust layer afterwards.

Today's scope: resource-side trust

This release covers the resource-side trust layer: the side of resource providers and data issuers. In other words, an agent can now confirm cryptographically who issued a piece of data, how much it paid for it, and that the bytes arrived intact.

The other half — the agent-side trust layer, answering who paid, under what authority, and under what policy — is the next milestone. In today's release the paying agent is identified by a wallet address; binding it to a did:key, attaching role and spend-limit attestations, all of that comes next.

We chose to ship the two layers in stages on purpose. The resource-side layer is already useful by itself: an agent operating in the existing x402 economy can extract verifiable data starting today. The agent-side layer is designed to compose independently, so adding it later does not invalidate any of the resource-side proofs already produced.

The agent side, next

The agent-side trust layer aims to turn a paying agent from an anonymous wallet into a verifiable principal.

Concretely, this means identifying the agent as a did:key principal, expressing authority through roles and scopes, making spend limits explicit through spendLimit, and managing credential lifecycle (issuance and revocation) — all expressed as ZK predicates so they can be verified.

When this lands, PAYMENT-RESPONSE will carry an attestation along the lines of "this payment was issued by did:key:..., operating under org:acme with payments:read scope, within spend limit, valid and unrevoked at the moment of settlement." That is the point at which the resource-side trust layer and the agent-side trust layer compose into the unified design previewed in the whitepaper.

Swap the schema, use it on any data

The reference implementation runs on a blog-article attribute schema (author, publication date, language), but that was chosen as the most legible example. The same machinery applies directly to other data types.

The four-phase flow — fetch → pay → ZK-verify — does not depend on the data itself in any way. By swapping the schema (the definition of which attributes to verify) and the circuit (the ZK proof of the verification logic), the exact same plumbing carries over to a different domain.

The core capability is that a paying agent can know, cryptographically, who issued whatever it just paid for and that the bytes it received match what was settled for. That capability reaches into broad domains precisely because schema and circuit are interchangeable.

x402 and MCP (α): two surfaces, one layer

In parallel, we are also publishing an early-stage α demo of an MCP server (lemma/packages/mcp) as a complementary surface. It is a locally installable demo — not a hosted, production service. The two share the same underlying trust layer and split responsibilities cleanly:

• x402 is the payment rail. The Lemma augmentation is settlement proof + ZK proof bundle in PAYMENT-RESPONSE.
• MCP (α demo, locally installable) is the read interface for MCP-native agents (Claude Desktop, Cursor, and similar). It exposes verified-attribute queries, schemas, circuits, generators, and proof status as tools. It works today, but expects local installation.

x402 is already agent-callable at the protocol level, so payments do not need an MCP wrapper. MCP exists to let agents that already speak it read from Lemma without a custom REST integration.

What's next

The next post in this series will cover the agent-side trust layer — DID binding, role / scope / spend-limit attestations — with a view of the full picture once both layers compose.

The demo runs without credentials — try it first. For teams evaluating production rollout and looking for pricing, plan details, or the whitepaper, please join the developer waitlist. Waitlist members also get access to the whitepaper PDF.
